SIZE |
A |
B |
C |
L |
ANSI 150B |
DIN PN 10 |
DIN PN 16 |
JIS 10K |
ISO 5211 |
Top |
|||||||
|
mm |
in |
øK |
N-M |
øK |
N-M |
øK |
N-M |
øK |
N-M |
øD |
øD1 |
N-ød |
|||||
|
40 |
1.5" |
70 |
164 |
32 |
33 |
98.5 |
4-1/2"-13UNC-2B |
110 |
4-M16 |
110 |
4-M16 |
105 |
4-M16 |
65 |
50 |
4-ø8 |
F05 |
|
50 |
2" |
80 |
169 |
32 |
43 |
120.6 |
4-5/8"-11UNC-2B |
125 |
4-M16 |
125 |
4-M16 |
120 |
4-M16 |
65 |
50 |
4-ø8 |
F05 |
|
65 |
2 1/2" |
89 |
176 |
32 |
46 |
139.7 |
4-5/8"-11UNC-2B |
145 |
4-M16 |
145 |
4-M16 |
140 |
4-M16 |
65 |
50 |
4-ø8 |
F05 |
|
80 |
3" |
95 |
183 |
32 |
46 |
152.4 |
4-5/8"-11UNC-2B |
160 |
8-M16 |
160 |
8-M16 |
150 |
8-M16 |
65 |
50 |
4-ø8 |
F05 |
|
100 |
4" |
114 |
201 |
32 |
52 |
190.5 |
8-5/8"-11UNC-2B |
180 |
8-M16 |
180 |
8-M16 |
175 |
8-M16 |
90 |
70 |
4-ø10 |
F07 |
|
125 |
5" |
127 |
214 |
32 |
56 |
215.9 |
8-3/4"-10UNC-2B |
210 |
8-M16 |
210 |
8-M16 |
210 |
8-M20 |
90 |
70 |
4-ø10 |
F07 |
|
150 |
6" |
139 |
229 |
32 |
56 |
241.3 |
8-3/4"-10UNC-2B |
240 |
8-M20 |
240 |
8-M20 |
240 |
8-M20 |
90 |
70 |
4-ø10 |
F07 |
|
200 |
8" |
175 |
257 |
45 |
60 |
298.4 |
8-3/4"-10UNC-2B |
295 |
8-M20 |
295 |
12-M20 |
290 |
12-M20 |
125 |
102 |
4-ø12 |
F10 |
|
250 |
10" |
203 |
280 |
45 |
68 |
361.9 |
12-7/8"-9UNC-2B |
350 |
12-M20 |
355 |
12-M24 |
355 |
12-M22 |
125 |
102 |
4-ø12 |
F10 |
|
300 |
12" |
242 |
327 |
45 |
78 |
431.8 |
12-7/8"-9UNC-2B |
400 |
12-M20 |
410 |
12-M24 |
400 |
16-M22 |
125 |
102 |
4-ø12 |
F10 |
